Instruments in the SKLplanets

Electron Probe

JXA-iSP100 (EPMA)

MAX 10 (EDS)

xClent (CL)

Scanning electron microscope

JSM-IT500 (SEM)

Max 170 (EDS)

Symmetry (EBSD)

Laser ablation system

GeoLas HD

Electron Probe

Scanning electron microscope

Laser ablation system

ICPMS

Agilent 7900

Ion implantor

Ion sources: gas + solid

Energy range: 0-70 kev

Temperature: -170ºC – 500 ºC

Laser Raman Microscope

Alpha300 R

ICPMS

Ion implantor

Laser Raman Microscope

Fourier transform infrared (FTIR) spectroscope

VERTEX 70v

Ultra-violet spectroscope

Lambda 950

Sample preparation facilities

Fourier transform infrared (FTIR) spectroscope

Ultra-violet spectroscope

Sample preparation facilities
